Wilwood 120-17080 HE1 Hydra-Electric Floating Mount Caliper Right 1 Piston
Manufacturer
Wilwood
Wilwood SKU WIL-120-17080
Price: €467.24
On demand
Wilwood 120-17080 HE1 Hydra-Electric Floating Mount Caliper Right 1 Piston
HE1 Hydra-Electric
These compact, low profile sliding mount HE1 Hydra-mechanical calipers can be utilized in recreational, industrial, utility, and other vehicles and are available in a 1.25” piston bore size. Fits rotors from 11.00” to 14.00” in diameter with a thickness range of .16” to .39”. Utilizing gearing and motor from our original Electronic Parking Brake Caliper.
| Pistons | |
|---|---|
| Piston Count | 1 |
| Piston Area (in²) | 1.23 |
| Piston Type | Stainless |
| Dust Boot | Yes |
| Rotor Dimensions | |
| Rotor Width (in) | 0.39 |
| Rotor Diameter(in) | 14.00 |
| Pad Dimensions | |
| Pad Area (in²) | 1.7 |
| Pad Volume (in³) | 0.26 |
| Duty Rating & Material | |
| Material | Cast Aluminium |
| Weight(Lbs) | 4.7 |
| Colors & Finish | |
| Color | Clear |
| Finish | Clear Anodize |
| Mounting | |
|---|---|
| Mount Center(in) | 4.75 |
| Mount Position | |
| Mount Side | Right Hand |
| Mount Type | Floating |
| Rotor Compatibility | |
|---|---|
| Rotor Width (in) | 0.39 |
| Maximum Rotor Width (in) | 0.39 |
| Minimum Rotor Width (in) | 0.15 |
| Maximum Rotor Diameter(in) | 14.00 |
| Minimum Rotor Diameter(in) | 11.00 |
| Piston Specifications | |
|---|---|
| Piston 1 Bore (in) | 1.25 |
| Piston 2 Bore (in) | |
| Piston 3 Bore (in) | |
| Total Piston Area (in²) | 1.23 |
More Information
| Manufacturer | Wilwood |
|---|
