Adapter IOD Performance Nissan Patrol BMW GS6-53DZ - Patrol transfer Sport Y61

BMW GS6-53DZ GEARBOX ADAPTER FOR NISSAN PATROL TRANSFER Sport CASE Y61

A complete assembly kit that allows for easy and quick connection of the BMW gearbox and the Nissan Patrol transfer case during conversion of the engine to BMW M57 3.0D.

• Fixed position of the transfer case, no need to modify the drive shafts.
• Installation using the original nissan patrol gearbox bar and mounts.
• Connecting shaft made of high-quality heat-treated chrome-molybdenum steel.
• Wide range of easily available clutch kits:
  • Single-disc.
  • Double-disc.
  • 1300Nm+ high-performance kits.
• Low weight of the complete set of BMW gearbox + adapter + Nissan transfer case.
• Possibility to install the engine in a higher position, without interfering with the partition wall of the vehicle - smaller diameter of the gearbox bell housing, compared to the zd30 gearbox.
• Precise gear selector
• Possibility to design the exhaust system within the frame.
• Easy assembly and disassembly due to the size and low weight of the gearbox.
• Sets available in sports version (with rigid connector) and comfort version (with flexible connector).

Adapter thickness 181mm

The set contains the following elements:

• Adapter.
• Connecting shaft (rigid or flexible).
• Gear lever with rubber covers.
• Cable with safeguards.
• Connecting shaft seal.
• Set of mounting screws.
