Wilwood 120-16070 Dynapro Single for VW Universal Lug Mount Caliper 2 Pistons Black

Manufacturer WilwoodWilwood
SKU WIL-120-16070-BK

  On demand



Wilwood 120-16070 Dynapro Single for VW Universal Lug Mount Caliper 2 Pistons Black

Dynapro Single VW

The Wilwood DynaPro Single-VW (DPS-VW) billet caliper is a further enhancement of our newest generation of calipers available as an upgrade or replacement for select VW models. DPS-VW calipers combine superior strength with design and performance enhancements to make these one of the best and lightest OE replacement calipers. Utilizing easily sourced #6812 pads that are available in multiple Street to High-Temperature Racing compounds, further enhance the DPS-VW calipers utility.

Calipers are fully CNC machined from premium grade alloy billet. The FEA generated body design incorporates a fortified transition between the piston housings and the bridges. Strengthening this critical area has substantially increased its resistance to deflection and body separation under load. Reductions in overall deflection, and the subsequent decreases in fluid volume displacement, translate to increased clamping efficiency with less pedal travel.

The DPS-VW uses 1.62" (41mm) bore heavy wall stainless steel pistons to resist corrosion and slow the heat transfer from the pads. The heavy wall sectional thickness improves pedal firmness and adds to the overall clamping efficiency by eliminating piston backside deflection.

Pistons
Piston Count 2
Piston Area (in²) 2.06
Piston Type Stainless
Dust Boot No
Rotor Dimensions
Rotor Width (in) 0.38
Rotor Diameter(in) 13.00
Pad Dimensions
Pad Area (in²) 3
Pad Volume (in³) 1.1
Duty Rating & Material
Material Billet Aluminium
Weight(Lbs) 2.3
Colors & Finish
Color Black
Finish Black Powder Coat

Mounting
Mount Center(in) 2.22
Mount Position
Mount Side Universal
Mount Type Lug

Rotor Compatibility
Rotor Width (in) 0.38
Maximum Rotor Width (in) 0.38
Minimum Rotor Width (in) 0.25
Maximum Rotor Diameter(in) 13.00
Minimum Rotor Diameter(in) 6.00


Piston Specifications
Piston 1 Bore (in) 1.62
Piston 2 Bore (in)
Piston 3 Bore (in)
Total Piston Area (in²) 2.06
